TA Card Readers TR512A

FEATURES:

• Promag TR-512A Magnetic Card Time Recorder
• Validated and stores the personal number read from the barcode card of the of the accessing card holder. The length of the personal ID number can be selected from 2 to 36 digits
• The access code or password for each company and the departments in the same company can be programmed with a different code
• Handles up to 16 different department within a company
• Allows 28 selections of alarm on time interval
• Gate open period is programmable, up to 59 seconds
• Provides RS-232 communication interface. RS-422 interface are optional
• Up to 31 devices can be connected via RS-232 or RS-422 interfaces
• Internal Battery provides up to 2 months of memory retention in the event of power failure
• Contains 64K bytes of user memory buffer, can store up to six thousands of individual records
• Provides eight (8) selectable function keys
• Baud rate and parity are able to be changed if necessary
• Audio feedback to indicate correct or erroneous card input
• Provides driver port for external buzzer connections
• provides driver port for external gate open/code controls
